Case Front Axle Steering Cylinder and Axle Shaft

Click on each number to jump to the product page. Each number on the image is a "Ref #" that can be matched on the table below.

Case Front Axle Steering Cylinder and Axle Shaft parts list
REF #	Image	Fits Model	Description	Part #	Price	Product Details
1-4	See Details	570LXT, 570MXT, 580L, 580 Super L, 580M, 580 Super M, 585G, 586G, 588G	Steering Arm Assembly	144457A1	$108.00	View Info
1-4	See Details	580 Super M Plus (Wide Track)	Steering Arm Assembly	313260A1	$182.00	View Info
1-4	See Details	570N EP, 580N, 586H, 588H	Steering Arm Assembly	84547078	$114.00	View Info
1	See Details	570LXT, 580MXT, 580L, 580M, 580 Super L, 580 Super M, 585G, 586G, 588G	Tie Rod	87710157	$74.00	View Info
2	See Details	570LXT, 570MXT, 580L, 580 Super L, 580M, 580 Super M, 580N, 580 Super N, 585G, 586G, 588G, 586H, 588H	Jam Nut, Tie Rod	906009R1	$4.00	View Info
3	See Details	570LXT, 570MXT, 580L, 580 Super L, 580M, 580 Super M, 580N, 580 Super N, 585G, 586G, 588G, 586H, 588H	Swivel Joint, Steering Arm (4WD)	112509A1	$44.00	View Info
4	See Details	570LXT, 580MXT, 580L, 580 Super L, 580M, 580 Super M, 585G, 586G, 588G	Steering Tie Rod End Lock Nut	85805982	$4.50	View Info
5	See Details	570LXT, 570MXT, 580L, 580 Super L, 580M, 580 Super M, 585G, 586G, 588G	Power Steering Cylinder (4WD)	144458A1	$525.00	View Info
	See Details	570MXT-III, 580M-III, 580 Super M-III, 570NXT-4A, 586G-3, 588G-3, 586H-4, 588H-4	Steering Cylinder (4WD)	87685547	$694.00	View Info
8	See Details	570LXT, 570MXT, 585G, 586G, 588G, 580K (After Serial Number JJG0020000 4-Bolt Steering Cylinder), 580SK, 580L, 580SL, 580M, 580SM, 590 Turbo, 590 Super L, 590 Super M	Steering Cylinder Seal Kit (Four-Wheel Drive)	D149739	$64.00	View Info
8-11	See Details	570LXT, 570MXT, 580L, 580 Super L, 580M, 580 Super M, 580N, 580 Super N, 585G, 586G, 588G, 586H, 588H	Front Axle Shaft Assembly (OEM)	144461A1	$594.00	View Info
11	See Details	570LXT, 570MXT, 570NXT, 580L, 580 Super L, 580M, 580 Super M, 585G, 586G, 588G	Short Shaft, Front Axle Drive Shaft	144463A1	$195.00	View Info
8	See Details	570LXT, 570MXT, 570NXT, 580L, 580 Super L, 580M, 580 Super M, 585G, 586G, 586H, 588G, 588H.	Long Shaft, Front Axle Drive Shaft	144462A1	$485.00	View Info
8	See Details	580 Super M Plus (Series II & III) (After Ser # N4C307000)	Long Shaft, Axle Drive (Wide Track)	390027A1	$550.00	View Info
9	See Details	480F, 480F LL, 580K, 580SK, 580L, 580SL, 580M, 580SM, 590 Turbo, 590SL, 590SM I & II, 570LXT, 570MXT, 584E, 585E, 586E, 585G, 586G, 588G, 586H, 588H, 760, 860, 555C, 555E, 575D, 575E, 655C, 655D, 655E, 675D, 675E, LB75, LB75SCP, 345C, 345D, 445D, 455	U-Joint, Front Axle Drive Shaft	144465A1	$49.00	View Info
	See Details	570LXT, 570MXT, 580L, 580 Super L, 580M, 580 Super M, 590 Super L, 585G, 586G, 588G	Guard Bracket, Drive Shaft	137223A2	$174.00	View Info
	See Details	570LXT, 580MXT, 580L, 580M, 580 Super L, 580 Super M, 585G, 586G, 588G	Drive Shaft Yoke, Front Axle	144280A1	$133.00	View Info
	See Details	570LXT, 570MXT, 570NXT, 580L, 580 Super L, 580M, 580 Super M, 590 Super L, 590 Super M, 585G, 586G, 588G, New Holland LV80, U80, U80B, 80C	Axle Drive Shaft Yoke	144279A1	$134.00	View Info
	See Details	480F, 480F LL, 580K, 580 Super K, 580L, 580 Super L, 580M, 580 Super M, 580N, 590 Turbo, 590 Super L, 590 Super M, 570LXT, 570MXT, 570NXT, 584E, 585E, 585G, 586E, 586G, 588G, 588H, 760, 860	Snap Ring (Front Axle Drive Shaft)	N14410	$2.00	View Info
	See Details	580L, 580 Super L, 580M, 580 Super M, 570LXT, 570MXT, 585G, 586G, 588G	Steering Cylinder	144458A1-OEM	$790.00	View Info
	See Details	580M, 580 Super M, 580N, 580N EP, 580 Super N, 590 Super M, 590 Super N, 570N EP, 586H, 588H	Front Axle Driveshaft Assembly (4WD)	87694656	$494.00	View Info

4WD front axle steering cylinders, tie rod assemblies, drive shafts, U-joints, yokes, and related components for Case 580L, 580M, 580N, and related backhoe loaders.

Fits Models At A Glance

480F Series: 480F, 480F LL
570 Series: 570LXT, 570MXT, 570MXT Tier 3, 570NXT, 570N EP
580K / 580SK Series: 580K, 580SK
580L / 580 Super L Series: 580L, 580SL, 580 Super L
580M / 580 Super M Series: 580M, 580M Series III, 580SM, 580SM Series II, 580SM Series III, 580 Super M, 580 Super M Series III, 580 Super M Plus, 580 Super M Plus Series II, 580 Super M Plus Series III
580N / 580 Super N Series: 580N, 580 Super N
590 Series: 590 Turbo, 590SL, 590SM, 590SM Series I, 590SM Series II, 590 Super L, 590 Super M

Key Notes

Application: 4WD front axle steering and drive shaft components for Case backhoe loader front axle systems
Coverage: Includes steering arm assemblies, tie rod assemblies, tie rod ends, swivel joints, jam nuts, lock nuts, power steering cylinders, steering cylinder seal kits, front axle shaft assemblies, short and long drive shafts, wide track long axle shafts, U-joints, drive shaft yokes, drive shaft guards, and snap rings
Function: Maintains 4WD front axle steering, tie rod, drive shaft, and U-joint function on Case 580L through 590 Super M backhoe loader platforms
Fitment Note: Wide track and standard configurations require different long axle shafts — verify track width when ordering
