Kubota Tie Rod 7-7/8" - M5040, M6040, M7040, M7060 4WD Front Steering

SKU:
3C011-62920
FitsModel:
M4-071HDC12, M4D-061HDC12, M4D-071HDC12, M5040, M5140, M6040, M6060, M7040, M7060
ListDescription:
Tie Rod, 4WD
Kubota 3C011-62920 tie rod, 7-7/8 inch ball joint to end
Part # 3C011-62920

Fits Models At A Glance:

  • Kubota M4-071: M4-071HDC12
  • Kubota M4D-061: M4D-061HDC12
  • Kubota M4D-071: M4D-071HDC12
  • Kubota M5040: M5040, M5040DT, M5040DT-1, M5040DTC, M5040DTC-1, M5040HD, M5040HD-1, M5040HDC, M5040HDC-1
  • Kubota M5140: M5140
  • Kubota M6040: M6040, M6040DT, M6040DT-1, M6040DTC, M6040DTC-1, M6040HD, M6040HD-1, M6040HDC, M6040HDC-1
  • Kubota M6060: M6060, M6060HD, M6060HDC
  • Kubota M7040: M7040, M7040DT, M7040DT-1, M7040DTC, M7040DTC-1, M7040HD, M7040HD-1, M7040HDC, M7040HDC-LTD, M7040HDC-1, M7040SUD, M7040SUHD
  • Kubota M7060: M7060, M7060HD, M7060HDC, M7060HDC12, M7060HD12

Key Notes:

  • Part Type: Tie Rod — front axle steering tie rod
  • Part Number(s): 3C011-62920
  • Side Fitment: One hand of a left/right-hand pair — confirm which side you need; do not order for the opposite side
  • Center of Ball Joint to End: 7-7/8" (7.88")
  • Internal Threads: M20 x 1.5 Right-Hand Thread
  • Stud Threads: M18 x 1.5 Right-Hand Thread
  • Related Part: Pairs with the steering cylinder tie rod assembly 3C011-62970 on the same models
  • Application: Front axle steering linkage tie rod
  • Weight: 2.75 lbs
  • Condition: Aftermarket replacement part

Common Use Case or Symptoms:

Use when there is play or clunking in the front steering, the wheels don't track straight, or the front tires show uneven wear — a worn tie rod lets the steering geometry shift under load, and the ball joint end is a common wear point that develops slop long before the rod itself fails.

Why Choose Broken Tractor:

✅ Thread Specs Listed Both Ends – M20 and M18 right-hand threads spelled out so you match your linkage without measuring twice
✅ Wide 4WD M-Series Coverage – one tie rod spans the M5040 through M7060 lineup across DT, HD, and HDC configurations
✅ Fast Shipping from a U.S.-Based Team – ready to ship from our U.S. warehouses

$149.00
