Steering to Frame Pivot Pin for John Deere 648L, 848L, 948L, 643L, 843L – AT413581

SKU:
AT413581
FitsModel:
640L, 648L, 748L, 848L, 948L, 640L-II, 648L-II, 748L-II, 848L-II, 948L-II, 643L, 643L-II, 843L, 843L-II
ListDescription:
Steering to Frame Pivot Pin
Steering to frame pivot pin AT413581 for John Deere 648L grapple skidder
Part # AT413581

Fits Models At A Glance:

  • John Deere Forestry – L Series Skidders: 640L, 648L, 748L, 848L, 948L
  • John Deere Forestry – L-II Series Skidders: 640L-II, 648L-II, 748L-II, 848L-II, 948L-II
  • John Deere Forestry – Wheeled Feller Bunchers: 643L, 643L-II, 843L, 843L-II

Key Notes:

  • Part Numbers: AT413581, AT561869
  • Type: Steering to frame pivot pin
  • Dimensions: 49.5 mm (1.95 in) diameter x 169 mm (6.65 in) long
  • Weight: 7.54 lbs (3.42 kg)
  • Application: Connects the steering cylinder to the frame at the articulation joint on John Deere L Series skidders and wheeled feller bunchers. The pin is the pivot point the cylinder works against to steer the machine left and right.
  • Material: Heat-treated steel with a plated finish for wear and corrosion resistance
  • Condition: Replacement Part for John Deere Equipment

Common Use Case or Symptoms: Use when there is play or clunking at the steering cylinder mount, steering feels loose or delayed, or the pin is worn, grooved or scored — a worn steering pin lets the frames shift and wears out the cylinder eye and frame bores.

Why Choose Broken Tractor:

  • ✅ Measured 49.5 mm Pin You Can Check Against Yours – diameter and length listed
  • ✅ Fits L and L-II Skidders and Feller Bunchers – one pin across the L-series platform
  • ✅ Fast Shipping from a U.S.-Based Team – ready to ship from our U.S. warehouses
$124.04

Shipping calculated at checkout. If any item in your order is temporarily unavailable, we'll contact you to arrange a back-order or refund — whichever you prefer.
