Ford TW-25 Tractor

SKU:
Ford-TW25-Tractor-Specs
Ford TW-25 pulling agricultural equipment, demonstrating its versatility.
Fits Models:
Placeholder
Part # Ford-TW25-Tractor-Specs

Description:

Serial Number Location

The serial number for the Ford TW-25 can typically be found:

  • Stamped on the engine block, near the starter

  • Metal tag riveted to the transmission housing or right side frame rail

Serial Numbers by Year:

Year Serial Number Start
1983 C700000
1984 C713000
1985 C728000
1986 C743000
1987 C758000
1988 C773000
1989 C788000

Key Specifications

Feature Specification
Engine 6.6L (401 cu in) 6-cylinder turbocharged diesel
Horsepower 156 HP (116.3 kW)
PTO Power 140 HP (104.4 kW)
Transmission Options 16-speed partial power shift, or 24-speed with creeper
Fuel Capacity 100 gallons (378.5 liters)
Operating Weight Approx. 13,649 lbs (6,190 kg)

Hydraulic System

Feature Specification
Type Closed center
Pump Flow 23.8 gpm (90.1 lpm)
3-Point Hitch Category III

Tire Sizes

  • Front: 14L-16.1 SL

  • Rear: 20.8-38

Key Features

  • High-Horsepower Performance – 156 HP turbocharged diesel engine built for large implements and tough jobs

  • Transmission Versatility – Choose between 16-speed power shift or 24-speed creeper for specialized work

  • Heavy-Duty Capability – Category III hitch and high flow closed-center hydraulics support large implements

  • Extended Work Time – 100-gallon fuel tank ensures fewer refueling interruptions

  • Built for Commercial Ag – Ideal for plowing, tillage, grain cart work, and more demanding field applications

Common Replacement Parts

Browse Ford TW-25 tractor parts designed to keep your machine running at peak performance:

Engine & Fuel

  • Turbochargers, injector pumps, fuel filters, thermostats

Transmission

  • Power shift solenoids, clutch packs, gear synchronizers

Hydraulics

  • Pumps, control valves, 3-point lift cylinders, remotes

Rear Axle & PTO

  • PTO shafts, drawbars, stabilizers, planetary gears

Electrical

  • Alternators, starter motors, dash clusters, lighting kits

Maintenance Schedule

Task Recommended Interval
Engine Oil & Filter Every 100 hours
Fuel Filter Replacement Every 200 hours
Air Filter Cleaning Monthly or in dusty conditions
Hydraulic Filter Change Every 400 hours
Coolant Flush Every 2 years
Greasing Points Weekly or before heavy-duty operations

Information Guide Only
