Caterpillar publishes no replacement or superseding number for 109-3622.
Easy to confuse with 1139539 (Caterpillar 113-9539). Both modules are the same 1491 mm length and differ by about 8 mm in height - Caterpillar itself shows 109-3622 as a related part on the 113-9539 page. Measure the module you are replacing; the two are not interchangeable.
Caterpillar's catalog adds the 657 and 657B wheel scrapers to the machines the supplier list carries.
Key Notes:
Part Number: 1093622 (Caterpillar reference 109-3622)
Type: Modular radiator core section - one module, not a complete radiator
Construction: Caterpillar Advanced Modular Cooling System module
Dimensions: 1491 mm x 140 mm
Material: Carbon steel with alloy mixed metals
Weight: 46.0 lbs.
Condition: Aftermarket replacement part
Application: Replaces an AMOCS radiator core module on Caterpillar D6R, D10N and D10R tractors, 621G through 627G wheel tractors, 966G II and 972G II loaders and 572R through 587R pipelayers
Shipping Restrictions: Ships to the lower 48 US states only
Note: This is ONE module. An AMOCS radiator is built from a stack of these, so count what the machine carries before ordering. End tanks, seals, spacers, frame and hardware are not included. Check the module height against 113-9539 before ordering. Ships LTL freight.
Common Use Case or Symptoms:
Reach for these when a machine is losing coolant from one section of the stack, or when a rock or a stick has gone through a single module - the whole point of AMOCS is that the damaged strip pulls out on its own, so one module beats condemning a radiator that costs several thousand dollars.
Why Choose Broken Tractor?
✅ AMOCS Modular Design: Caterpillar's Advanced Modular Cooling System - a stack of independent strips, any one of which can be pulled and replaced alone.
✅ Five Machine Types One Strip: Dozers, wheel tractors, scrapers, loaders and pipelayers all take the same module, which is unusual breadth for a cooling part.
✅ Height Is The Difference: Two AMOCS modules share this length and differ only in height, so the listing points at the other one by number.
$752.00/ea
