Modular Radiator Core for Caterpillar 631G & 637G Wheel Tractors | 1192166

SKU:
1192166
FitsModel:
631G, 637G
ListDescription:
Modular Radiator Core
Modular Radiator Core for Caterpillar 631G & 637G Wheel Tractors | 1192166
Part # 1192166

Fits Models At A Glance:

  • Caterpillar Wheel Tractor Scrapers: 631G, 637G

Serial Number Notes:

  • 631G: AWK00001-UP, AXZ00001-UP
  • 637G: AXT00001-UP, AYN00001-UP, AWE00001-UP

Superseding & Cross-Reference Numbers:

  • Caterpillar publishes no replacement or superseding number for 119-2166.
  • Caterpillar lists these items with this module, stocked separately: end tank seal 4P-9942, fan end tank seal 4P-9943, radiator gaskets 4N-1418 and 4N-1419, and v-belt 4N-8221.

Key Notes:

  • Part Number: 1192166 (Caterpillar reference 119-2166)
  • Type: Modular radiator core section - one module, not a complete radiator
  • Construction: Stacked modular cooling section, coolant carried through internal tubes and channels
  • Material: Carbon steel, structural steel and alloy mixed metal
  • Weight: 40.1 lbs.
  • Condition: Aftermarket replacement part
  • Application: Replaces a radiator core module on Caterpillar 631G and 637G wheel tractor scrapers
  • Shipping Restrictions: Ships to the lower 48 US states only
  • Note: This is ONE module. The scraper's radiator is built from a stack of them, so count how many need replacing before ordering. End tanks, seals, gaskets, frame and hardware are not included. Caterpillar publishes no dimensions for this module; measure the section being removed. Ships LTL freight.

Common Use Case or Symptoms:

Fit these when a 631G or 637G is running hot after a season of push-pull loading, or when one section of the stack is weeping - a scraper spends its life in the dust it makes, and the modules plug from the face long before anything actually fails.

Why Choose Broken Tractor?

  • ✅ Scraper Duty Cooling: Built for the 631G and 637G, which work in their own dust cloud and ask more of a cooling pack than almost anything else on a job.
  • ✅ Replace Only What Failed: Modular sections mean the intact strips stay in the machine and only the damaged one is bought.
  • ✅ Seals And Gaskets Listed: Five related service items are named in the listing, so a module swap does not stall waiting on a gasket.
$759.00
