Engine Radiator Core for Caterpillar 318C, 319C & 320C Excavators | 1932767

Fits Models At A Glance:

• Caterpillar Hydraulic Excavators: 318C, 319C, 320C, 320C FM

Serial Number Notes:

• 318C: BTG00001-UP, CWP00001-UP, DAH00001-UP, FAA00001-UP, GPA00001-UP, MDY00001-UP
• 319C: KGL00001-UP
• 320C: AKH00001-UP, ALF00001-UP, ALX00001-UP, AMC00001-UP, ANB00001-UP, APA00001-UP, AXK00001-UP, BBL00001-UP, BCB00001-UP, BCN00001-UP, BDB00001-UP, BDC00001-UP, BDE00001-UP, BEA00001-UP, BER00001-UP, BMZ00001-UP, BPR00001-UP, BRX00001-UP, CLM00001-UP, CLZ00001-UP, DBG00001-UP, EGA00001-UP, EGL00001-UP, FBA00001-UP, FBB00001-UP, GAA00001-UP, GAB00001-UP, GAD00001-UP, GLA00001-UP, GNG00001-UP, HBC00001-UP, HKT00001-UP, JPL00001-UP, JTG00001-UP, MAA00001-UP, MAB00001-UP, MAC00001-UP, MSN00001-UP, PAA00001-UP, PAB00001-UP, PAC00001-UP, RAW00001-UP, SBN00001-UP
• 320C FM: BGB00001-UP, BKK00001-UP, SAH00001-UP, TBR00001-UP

Superseding & Cross-Reference Numbers:

• Caterpillar marks 193-2767 discontinued and publishes no replacement number, directing buyers to a dealer for options. This listing continues the original reference.
• 2364430 (Caterpillar 236-4430) is the complete water radiator for the 320C. This number is the core alone - order the complete unit if you have no way to transfer tanks.

Key Notes:

• Part Number: 1932767 (Caterpillar reference 193-2767)
• Type: Engine radiator core - core only, no tanks or frame
• Dimensions: 860 mm x 1015 mm x 150 mm
• Material: Alloy aluminium
• Weight: 71.0 lbs.
• Condition: Aftermarket replacement part
• Application: Replaces the engine radiator core on Caterpillar 318C, 319C, 320C and 320C FM hydraulic excavators
• Shipping Restrictions: Ships to the lower 48 US states only
• Note: Core only - tanks, side frames, hoses, cap, shroud and mounting hardware are not included. This is a tall core at 1015 mm high and 150 mm deep, unlike the wide shallow coolers elsewhere in this machine's pack. Caterpillar publishes 66.14 lbs against the supplier's 71 lbs. Ships LTL freight; inspect fins and tube ends on arrival.

Common Use Case or Symptoms:

Fit this when a C Series excavator creeps up the gauge under load with a clean fan and good belts, or when the core is weeping at a tube-to-header joint - aluminium cores go at the joints rather than through the tube walls, so the leak shows up at the top or bottom edge first.

Why Choose Broken Tractor?

• ✅ No Dealer Replacement: Caterpillar has retired this number without naming a successor, which leaves a running 320C with nowhere else to go.
• ✅ Aluminium Core Construction: Alloy aluminium as Caterpillar built it, which is lighter than a copper core of the same face area and repairs differently.
• ✅ Deep Tall Core: 150 mm deep and 1015 mm tall - the dimensions are the reliable way to separate this from the other coolers in the same pack.
