Female Flat Face Hydraulic Quick Coupler for Case SR130, SR150–SR250, SV185–SV300, TR270–TV380 | 84390118

Fits Models At A Glance:

• Case Skid Steer Loaders: SR130, SR150, SR175, SR200, SR210, SR220, SR250, SV185, SV250, SV300
• Case Compact Track Loaders: TR270, TR320, TV380

Key Notes:

• Part Number: 84390118
• Interchange Numbers: 6680018, V0511-77150
• Coupler Type: Female flat face hydraulic quick coupler
• Standard: ISO 16028 — compatible with all standard 1/2" body ISO 16028 flat face couplers
• Thread Diameter: 46mm (4BD4FI manifold block)
• Pressure Rating: 5,076 PSI
• Design: Flush face valve — minimizes hydraulic fluid loss and air inclusion during connect/disconnect; allows connection under pressure
• Companion Male Coupler: 84390117 — sold separately
• Application: Auxiliary hydraulic circuit quick coupler — the female receiver half of the flat face quick connect system on applicable Case skid steer and compact track loaders, used to connect hydraulic attachment hoses to the machine's auxiliary hydraulic circuit
• Sold: Individually — female coupler only
• Condition: Aftermarket replacement part

Common Use Case or Symptoms: Use when the female coupler is leaking, damaged, will not lock onto the male coupler, or no longer seals properly under pressure — a failed hydraulic coupler causes fluid loss, pressure drop, and loss of attachment function on applicable Case skid steer and compact track loader equipment.

Why Choose Broken Tractor:

• ✅ Two Interchange Numbers Cross-Referenced: 84390118 interchanges with 6680018 and V0511-77150 — confirmed so you find the correct coupler regardless of which number appears in your parts manual or service records.
• ✅ ISO 16028 Flat Face Standard: Compatible with all standard 1/2" body ISO 16028 flat face couplers — the flush face design eliminates trapped air pockets and minimizes spillage during attachment connect and disconnect, keeping the hydraulic system cleaner.
• ✅ High Pressure Rated: 5,076 PSI pressure rating engineered for the auxiliary hydraulic circuits of applicable Case skid steer and compact track loader equipment.
