JD Tractor Tie Rods & Tie Rod Tubes

ⓘ Click headers to sort ↕
JD Tractor Tie Rods & Tie Rod Tubes parts list
Image Fits Model Description Part # Price Product Details
John Deere Complete Tie Rod - Fits 2510-4320 Row Crop Tractors - AR44332 See Details 2510, 2520, 3010, 3020, 4000, 4010, 4020, 4230, 4320 Complete Tie Rod AR44332
$138.00
View Info
John Deere Outer Tie Rod, 15 Groove - Fits 1020-2640 Utility Tractors - AT23583 See Details 1020, 1520, 1530, 2020, 2030, 2040, 2240, 2440, 2630, 2640 Outer Tie Rod AT23583
$42.00
View Info
John Deere Tie Rod End M20 x 1.5 / M18 x 1.5 RH - Fits 1640-2850 - AL39320 See Details 1640, 2040, 2040S, 2140, 2350, 2355, 2550, 2555, 2650, 2750, 2850 Tie Rod Swivel Joint (4WD) AL39320
$63.00
View Info
John Deere Tie Rod End M18 x 1.5 RH - Fits 1640-2850 Utility Tractors - AL39319 See Details 1640, 2040, 2040S, 2140, 2350, 2355, 2550, 2555, 2650, 2750, 2850 Tie Rod End AL39319
$88.00
View Info
John Deere Inner Tie Rod, Wide Front - Fits 4030-4455 Tractors - AR63588 See Details 4030, 4040, 4050, 4055, 4230, 4240, 4250, 4255, 4430, 4440, 4450, 4455 Inner Tie Rod AR63588
$32.00
View Info
John Deere MFWD Tie Rod End - Fits 2040S, 2140, 2940, 3040, 3140 - AL37523 See Details 2040S, 2140, 2940, 3040, 3140 Tie Rod End AL37523
$47.00
View Info
John Deere Tie Rod End, 6 Notch - Fits 1640-3255 Utility Tractors - AL37505 See Details 1640, 1830, 1840, 2030, 2040, 2040S, 2130, 2140, 2250, 2350, 2355, 2450, 2550, 2555, 2650, 2755, 2850, 2940, 2955, 3055, 3255 Tie Rod End AL37505
$32.00
View Info
John Deere Tie Rod 24mm - Fits 1830-2850 Utility Tractors - AL82826 See Details 1830, 1840, 2030, 2040, 2040S, 2130, 2140, 2250, 2350, 2355, 2450, 2550, 2555, 2650, 2750, 2755, 2850 Tie Rod AL82826
$32.00
View Info
John Deere MFWD Tie Rod, Left Hand M28 x 1.5 - Fits 2955-3650 - AL68254 See Details 2955, 3040, 3050, 3055, 3140, 3150, 3155, 3255, 3350, 3640, 3650 Tie Rod, L/H AL68254
$77.00
View Info
Tie Rod, Long Outer for John Deere 301, 1020 & more – AT27134 See Details 301, 401, 1020, 1030, 1040, 1120, 1130, 1140, 1350, 1520, 1530, 1550, 1630, 1640, 1750, 1850, 1950, 1950N, 2020, 2030, 2035, 2120, 2135, 2150, 2155, 2240, 2250, 2350, 2355, 2355N, 2440, 2550, 2555, 2630, 2640, 2755, 2855N, 840, 940 Tie Rod, Long Outer AT27134
$44.00
View Info
Tie Rod, Inner for John Deere 401B, 300, 300 & more – AT27130 See Details 401B, 300, 301, 302, 400, 401, 820, 2020, 1020, 1030, 1030OU, 1035EF, 1040, 1120, 1130, 1140, 1140F, 1350, 1520, 1530, 1550, 1630, 1630OU, 1635EF, 1640, 1640F, 1641, 1641F, 1750, 1840, 1840F, 1850, 1850N, 1950, 1950N, 2030, 2030OU, 2035, 2035EF, 2040 Tie Rod, Inner AT27130
$54.00
View Info
Tube, Tie Rod for John Deere 301, 1020 & more – T29109 See Details 301, 401, 1020, 1030, 1040, 1120, 1130, 1140, 1350, 1520, 1530, 1550, 1630, 1640, 1750, 1850, 1950, 2020, 2030, 2120, 2150, 2155, 2240, 2250, 2350, 2355, 2550, 2555, 2630, 2640, 2755, 840, 940 Tube, Tie Rod T29109
$53.00
View Info
Tube, Tie Rod for John Deere 401B, 301, 1020 & more – T25901 See Details 401B, 300, 301, 302, 400, 401, 1020, 1030, 1040, 1120, 1140, 1350, 1530, 1550, 1750, 1950, 1950N, 2020, 2030, 2040, 2150, 2155, 2240, 2355, 2355N, 2440, 2630, 2640, 2855, 2855N, 301A, 820, 830, 840, 920, 930 Tube, Tie Rod T25901
$26.00
View Info
Tube, Tie Rod for John Deere 300B, 300, 1020 & more – T22948 See Details 300B, 401B, 401C, 300, 302, 302A, 310, 380, 400, 401, 480, 480A, 480B, 1020, 1520, 2030, 301A Tube, Tie Rod T22948
$67.00
View Info
Tube, Tie Rod for John Deere 6410, SE6010 & more – L64250 See Details 6410, 6410L, 6410S, SE6010, SE6020, SE6100, SE6110, SE6120, SE6200, SE6210, SE6220, SE6300, SE6310, SE6320, SE6400, SE6410, SE6420, SE6510, SE6520, SE6610, SE6620, 2950, 2955, 3040, 3050, 3140, 3150, 3350, 6010, 6020, 6100, 6110, 6110L, 6120, 6120L Tube, Tie Rod L64250
$155.00
View Info
Tie Rod, 11 grooves for John Deere 300, 1020 & more – AT20943 See Details 300, 400, 1020, 1520, 2020 Tie Rod, 11 grooves AT20943
$87.00
View Info
Tube, Tie Rod for John Deere 300, 1020 & more – T22945 See Details 300, 400, 1020, 1520, 2020 Tube, Tie Rod T22945
$136.00
View Info
Tie Rod Assembly for John Deere 300B, 300, 1020 & more – AT19823 See Details 300B, 401B, 401C, 300, 302, 302A, 310, 380, 400, 401, 480, 480A, 480B, 1020, 1520, 2030, 301A Tie Rod Assembly AT19823
$124.00
View Info
Tie Rod Assembly for John Deere 301, 1030 & more – AR54637 See Details 301, 401, 1020, 1030, 1040, 1120, 1130, 1140, 1520, 1530, 1630, 1640, 1750, 2020, 2030, 2120, 2240, 2440, 2630, 2640, 840, 940 Tie Rod Assembly AR54637
$178.00
View Info
Ball Joint, Inner for John Deere 310, 500, 750 & more – AR74131 See Details 310, 310A, 310B, 410, 500C, 510, 750, 500, 2355, 2555, 2750, 2755, 5010, 5020, 6030 Ball Joint, Inner AR74131
$52.00
View Info
Tie Rod, Long for John Deere 401B, 300, 300 & more – AT23885 - view 2 See Details 401B, 300, 301, 302, 400, 401, 820, 2020, 1020, 1030, 1040, 1120, 1140, 1350, 1530, 1750, 1950, 1950N, 2030, 2040, 2150, 2155, 2240, 2250, 2255, 2355, 2355N, 2440, 2630, 2640, 2855, 2855N, 301A, 830, 840, 920, 930, 940 Tie Rod, Long AT23885
$60.00
View Info
Tie Rod, Inner for John Deere 300, 1020 & more – AT23886 See Details 300, 400, 1020, 1520, 1530, 2020, 2030, 2040, 2240, 2440, 2630, 2640, 530 Tie Rod, Inner AT23886
$59.00
View Info

Tie rods, tie rod tubes, inner and outer ball joints, and complete tie rod assemblies for John Deere two-wheel-drive tractor front axles, covering utility and row-crop models from the 300 series through the 6000 series.

Fits Models At A Glance

  • 300/400 Series: 300, 300B, 301, 301A, 302, 302A, 400, 401, 401B, 401C, 480, 480A, 480B
  • 1000 Series: 1020, 1030, 1040, 1120, 1130, 1140, 1350, 1520, 1530, 1630, 1640, 1750, 1850, 1950, 1950N
  • 2000 Series: 2020, 2030, 2040, 2120, 2150, 2155, 2240, 2250, 2355, 2440, 2550, 2555, 2630, 2640, 2755, 2855, 2855N
  • 6000 Series: 6010, 6110, 6120, 6410, SE6010-SE6620

Key Notes

  • Application: Steering linkage for two-wheel-drive front axles
  • Components: Inner and outer tie rods, tubes, ball joints, and assemblies
  • Configurations: Short, long, and grooved tie rod variants available
  • Fitment: Confirm axle type and part number before ordering

Why Choose Broken Tractor

  • ✅ Wide steering parts coverage for JD tractors
  • ✅ Fast shipping from two US locations
  • ✅ Knowledgeable support for correct fitment

Frequently Asked Questions

What tie rod parts fit a John Deere 1020 tractor?

Broken Tractor carries several tie rod parts listed for the John Deere 1020, including complete tie rod assemblies AR54637 and AT19823, tie rod tubes T22945, T22948, T25901 and T29109, inner tie rods AT23886 and AT27130, and outer tie rods AT27134 and AT23583. Because more than one version is listed for the 1020, the right part depends on your front axle setup. Match the part number stamped on or listed for your old part before ordering.

Do I need an 11 groove or 15 groove tie rod for a John Deere 1020 or 2020?

Both styles are listed for these models, so match the groove count on the tie rod you are replacing. We carry the AT20943 tie rod with 11 grooves, listed for the 300, 400, 1020, 1520 and 2020. We also carry the AT23583 outer tie rod with 15 grooves, listed for the 1020, 1520, 1530, 2020, 2030, 2040, 2240, 2440, 2630 and 2640. If you are not sure which one your tractor uses, call (800) 909-7060 to confirm fitment with the parts team.

What is the difference between a tie rod, a tie rod tube and a tie rod assembly on a John Deere tractor?

A tie rod assembly is the complete steering link, while tie rods, tie rod tubes and ball joints are sold as separate components. Broken Tractor offers complete assemblies such as AR54637, AT19823 and AR44332, plus individual inner and outer tie rods, tubes and inner ball joints. Buying individual components lets you replace only the worn piece, while a complete assembly replaces the whole link at once.

What tie rod tube fits a John Deere 6410 or SE6000 series tractor?

The L64250 tie rod tube is listed for the John Deere 6410, 6410L and 6410S, along with the SE6010 through SE6620 models. It is also listed for the 6010, 6020, 6100, 6110, 6110L, 6120 and 6120L. Confirm the part number against your existing tube before ordering.

What tie rods fit a John Deere 4020 or 4430 tractor?

For the John Deere 4020, Broken Tractor carries the AR44332 complete tie rod. That part is listed for the 2510, 2520, 3010, 3020, 4000, 4010, 4020, 4230 and 4320. For the 4430, we carry the AR63588 wide front inner tie rod, which is listed for the 4030, 4040, 4050, 4055, 4230, 4240, 4250, 4255, 4430, 4440, 4450 and 4455.
