Cat EL200B/318BL/320 Excavator Pins

Each number on the image is a "Ref #" that can be matched on the table below.

Cat EL200B/318BL/320 Excavator Pins parts list
REF #	Image	Fits Model	Description	Part #	Price	Product Details
	See Details	EL200B, 318BL, 318BLN, 320, 320L, 320B, 320BL	Shim & Seal Kit	PV7017	$441.00	View Info
1 & 2	See Details	EL200B, 318, 319DL, 319DLN, 320, 320B, 320L, 320C, 320CL, 320D, 320DL, 321DLCR	Pin, Bucket to Dipper Arm and Bucket to H-Link	0	087-5805	$397.00	View Info
3	See Details	EL200B, 318, 320, 320B, 320L, 320C, 320CL	Pin, Link to Dipper	0	087-5806	$304.00	View Info
4	See Details	EL200B, 318, 320, 320B, 320L, 320C, 320CL	Pin, Link to Cylinder	0	087-5845	$332.00	View Info
5	See Details	EL200B, 318, 320, 320B, 320L, 320C, 320CL	H-Link	166-1581	From $2,069.00	View Info
6	See Details	EL200B, 318, 320, 320B, 320L, 320BL, 320C, 320CL	Bushing, H-Link Closed End	0	143-3841	$78.00	View Info
7 & 14	See Details	315, 315B, 315C, 315L, 315BL, 315CL, EL200B, 318BL, 320, 320L, 320B, 320BL	Bushing, Dipper at Bucket / H-Link	137-2919	$78.00	View Info
8 & 9 & 15	See Details	EL200B, 318BL, 320, 320L, 320B, 320BL	Seal	0	096-0854	$19.00	View Info
10	See Details	EL200B, 318BL, 320, 320L, 320B, 320BL	Left Link to Dipper with Bolt Hole	0	087-5803	$483.00	View Info
11	See Details	EL200B, 318BL, 320, 320L, 320B, 320BL, 315, 315B, 315C, 315L, 315BL, 315CL	Right Link to Dipper (No Bolt Hole)	0	087-5802	$398.00	View Info
12	See Details	EL200B, 318, 320, 320B, 320L, 320C, 320CL	Bushing, Dipper at Bucket Link	0	163-3749	$76.00	View Info
13	See Details	EL200B, 318BL, 320, 320L, 320B, 320BL, 315, 315B, 315C, 315L, 315BL, 315CL	Seal	0	093-1434	$17.00	View Info
16	See Details	EL200B, 318BL, 320, 320L, 320B, 320BL, 312C, 312CL, 314C CR, 314C LCR, 312D, 312DL, 312E, 312EL, 314D CR, 314D LCR	O-Ring	0	093-1342	$12.00	View Info
	See Details	Universal – Fits dozers, excavators, loaders, and backhoes	Bushing Driver Removal Tool	BushingDriver	From $44.00	View Info

Pin Chart
Pins, bushings, links, seals, and shim kits for Caterpillar EL200B, 318BL, and 320 series excavators — covering bucket-to-dipper pins, link-to-dipper pins, link-to-cylinder pins, H-links with bushings, and associated seals and o-rings for bucket and dipper arm assemblies across multiple generations of Cat compact and mid-size excavators.

Fits Models At A Glance

EL200B Series: EL200B
318 Series: 318, 318BL, 318BLN
319 Series: 319DL, 319DLN
320 Series: 320, 320L, 320B, 320BL, 320C, 320CL, 320D, 320DL
321 Series: 321DLCR
315 Series: 315, 315B, 315C, 315L, 315BL, 315CL

Key Notes

Pin Types: Bucket-to-dipper, link-to-dipper, and link-to-cylinder pins available
Link Types: Right-hand, left-hand (with bolt hole), and H-link assemblies with bushings included
Seal & O-Ring Coverage: Seals and o-rings span EL200B through 320 series and select 312/314 series machines
Tooling: Bushing driver removal and installation tool available for service use
Shim Kits: Shim and seal kits cover EL200B, 318BL, and full 320 series variants
