Case Backhoe Shuttle Planetary & Valve Parts

Shop power shuttle planetary and valve parts for Case backhoe loaders. Broken Tractor stocks planetary shafts, bearings, valve assemblies, solenoids, seals, gaskets, O-rings, oil pans, filters, and rebuild kits to service and rebuild the internal components of your Case power shuttle transmission.

Fits Models At A Glance:

• Case 350 Series: 350, 350B
• Case 480 Series: 480C, 480D, 480E, 480F, 480LL
• Case 580 Series: 580C, 580D, 580 Super D, 580E, 580 Super E, 580K (Before Serial Number JJG0020000)
• Case 584/585/586 Series: 584C, 584D, 584E, 585C, 585D, 585E, 586C, 586D, 586E

Key Notes:

• Planetary Components: Planetary shaft lock nuts, output shaft washers, pinion cage and output shaft assemblies, planetary shaft bearing sleeves, needle bearings, and rear bearing retainers
• Valve Assemblies: Power shuttle control valve assemblies (male and female end), shuttle solenoids (late style), neutral start switches, and shuttle valve O-rings
• Seals & Gaskets: Output shaft yoke seals, sealing rings, shuttle seals, oil pan gaskets, valve cover gaskets, rear bearing retainer gaskets, and breathers
• Filters & Oil Pan: Metal and plastic oil pickup filters, oil pan drain plugs, oil deflector baffles, and used oil pans
• Rebuild Kits: Master rebuild kits with and without pump, torque converter kits, and seal/gasket/O-ring kits

Why Choose Broken Tractor:

✅ Planetary, Valve, and Seal Components In Stock

✅ Fits 480, 580, and 584/585/586 Series Backhoe Loaders

✅ Fast Shipping from U.S. Warehouses

Frequently Asked Questions

Do Case backhoe power shuttle parts fit a 580K?

Most of the shuttle planetary and valve parts we carry fit the Case 580K built before serial number JJG0020000, often listed as 580K Phase I. Later 580K machines are not covered by most of these parts, so check the serial number plate on your backhoe before ordering. Match the part number on your old component, or call (800) 909-7060 to confirm fitment.

What power shuttle rebuild kit fits a Case 580C?

Broken Tractor offers four kit options that fit the Case 580C power shuttle: the Power Shuttle Rebuild Kit (A574002), the Power Shuttle Master Rebuild Kit (A574015), a rebuild kit with pump and torque converter (CS-CPSK), and a seal, gasket and O-ring kit (D103220). The same kits also fit the 580D, 580 Super D, 580E, 580 Super E, the 580K before serial number JJG0020000, and the 480C through 480F. Pick the seal, gasket and O-ring kit for a reseal, or one of the rebuild kits for a full shuttle overhaul.

What is the difference between the male end and female end Case power shuttle valve assembly?

We carry the forward-reverse shuttle control valve assembly in two versions, a male end (N13639) and a female end (N14765), and they are not interchangeable. Look at the connection end on the valve currently in your Case 480 or 580 backhoe and order the matching style. Broken Tractor also offers a late style male shuttle solenoid assembly (N14766), a control valve O-ring (D37156), and a shuttle housing with a reman forward and reverse valve in oversize (D70650R).

Should I buy the metal or plastic power shuttle oil pickup filter for my Case 580D?

Both the plastic pickup filter (D66455) and the metal pickup filter (D66455-HD) come with a screen and fit the Case 580D, 580C, 580 Super E, 580K, and 480C through 480F. Choose whichever material you prefer. When the oil pan comes off, it is also a good time to replace the shuttle filter O-ring (R29797), the oil pan gasket (R29956), and the drain plug (D73701).

What parts do I need to rebuild the shuttle planetary on a Case 580 Super E?

For the Case 580 Super E, Broken Tractor carries the pinion cage output shaft with planetary gears (D70665), the planetary shaft lock nut (131-37), the planetary shaft bearing sleeve (D50057), and the planetary needle bearings (R21491 and H747964). We also offer the output shaft bearing (40011), the output shaft washer (D65247), the rear bearing retainer (D50059) with its gasket (D50058), and the output yoke seal (D50060). These parts also fit the 580C, 580D, the 580K before serial number JJG0020000, and the 480C through 480F.
