Case Backhoe Electrical

Electrical parts for Case backhoe loaders, including alternators, starters, switches, gauges, sensors, wiring harnesses, and relays across the 480, 580, and 590 series machines. Both new replacement and tested used components are available to keep your backhoe charging, cranking, and running.

Fits Models At A Glance

• 480 Series: 480B, 480C, 480D, 480E, 480F
• 580 Series: 580B, 580C, 580D, 580E, 580K, 580 Super K
• 580L Series: 580L, 580M, 580 Super L, 580 Super M
• 590 Series: 590 Super L, 590 Super M, 590 Super N

Key Notes

• Application: Charging, starting, lighting, gauges, and control circuits
• Components: Alternators, starters, switches, senders, harnesses, relays
• Condition: New replacement and inspected used parts offered
• Fitment: Varies by model and serial number range

Why Choose Broken Tractor

• ✅ New and used electrical parts in one place
• ✅ Coverage across 480, 580, and 590 series
• ✅ Fast shipping from two US locations

Frequently Asked Questions

Where is the battery located on a Case backhoe?

Battery location varies by model and generation, but on most Case backhoe loaders it sits in a compartment near the engine or under a side or rear panel. Because layout changed across the 480, 580, and 590 series, confirm your model before ordering related electrical parts.

How do I fix an electrical problem on a Case backhoe?

Start by checking the battery, ground connections, fuses, and the main charging components like the alternator and starter. Many issues trace back to corroded connectors or a failed switch or sender. We carry replacement alternators, starters, switches, and harnesses to address the most common faults.

How do I find the right electrical part for my Case backhoe?

Match your machine model and serial number to the part, since Case changed wiring and components across series. Comparing your old part number to the replacement is the most reliable method. If you are unsure, call our parts team at (800) 909-7060 and we will help confirm fitment.

Do you carry both new and used Case backhoe electrical parts?

Yes, we offer new replacement components along with tested used parts. Used options can be a cost effective choice for older 480 and 580 series machines. Availability depends on the specific part and model.
