Case Excavator Links, Pins & Bushings

Replacement bucket links, pivot pins, and bushings for Case excavators, covering H-links, dog bone links, and the full pin-and-bushing hardware that connects boom, arm, and bucket across compact and full-size models.

Fits Models At A Glance

• CX Series: CX130, CX160, CX210, CX240, CX290
• CX B Series: CX130B, CX160B, CX210B, CX240B
• Compact Series: CX36B, CX55B, CX75SR

Key Notes

• Application: Bucket linkage, boom-to-arm, and arm-to-bucket connection points
• Components: H-links, dog bone links, pivot pins, and bushings
• Condition: New and used options available depending on part
• Fit: Matched to OEM pin diameters and bore dimensions per model

Why Choose Broken Tractor

• ✅ Fast shipping from two US locations
• ✅ Fitment verified by machine model and serial
• ✅ New and used options to fit any budget

Frequently Asked Questions

What links, pins, and bushings do you carry for Case excavators?

Broken Tractor carries H-links, dog bone links, pivot pins, and bushings that connect the boom, arm, and bucket on Case excavators. These cover bucket linkage, boom-to-arm, and arm-to-bucket connection points. We offer parts for CX Series, CX B Series, and Compact Series models.

What Case excavator models do these pins and bushings fit?

We stock linkage hardware for the CX Series (CX130, CX160, CX210, CX240, CX290), the CX B Series (CX130B, CX160B, CX210B, CX240B), and the Compact Series (CX36B, CX55B, CX75SR). Fit is matched to OEM pin diameters and bore dimensions per model. Because fitment can vary by serial number, match the part number or confirm with our parts team before ordering.

How do I know which pin and bushing size I need for my Case excavator?

Pin and bushing parts are matched to OEM pin diameters and bore dimensions for each Case excavator model. The right size depends on your specific model and often the serial number, so measure the worn pin and bore or match against the OEM part number. Our parts team can help you confirm the correct fit at (800) 909-7060.

Can I buy used links, pins, and bushings for a Case excavator?

Yes, Broken Tractor offers both new and used options depending on the part. Used parts can be a lower-cost way to replace worn linkage hardware while keeping your excavator working. Availability of new versus used varies by component and model.

Should I replace worn excavator pins and bushings together?

Replacing worn pins and their matching bushings together is common because both wear over time at the same connection points and worn bores can quickly damage a new pin. We carry pins and bushings for the boom-to-arm and arm-to-bucket joints so you can renew the full connection. Match the part numbers for your Case excavator model to keep the fit correct.
