Case 580ST Tractor Loader - Parts, Specs & Common Issues

SKU:
Case 580ST Tractor Loader - Parts, Specs & Common Issues
Case 580ST Tractor Loader - Parts, Specs & Common Issues
Fits Models:
Placeholder
Part # Case 580ST Tractor Loader - Parts, Specs & Common Issues

Description:

Serial Number Location:

For Case 570ST Tractor Loaders (manufactured from 2013 to present), the serial number plate is typically located on the left side of the machine frame near the loader arm pivot area or beneath the operator platform. Always verify your serial number before ordering model-specific parts to ensure compatibility with your specific machine configuration.

Key Specifications

Feature Specification
Years Manufactured 2013 – Present
Engine Model FPT F5C (4-cylinder Tier 3 turbo diesel)
Gross Horsepower 76 HP (57 kW) @ 2,200 rpm
Max Torque 297 lb-ft (403 Nm) @ 1,400 rpm
Displacement 207 cu in (3.4 L)
Transmission Type 4-speed synchronized shuttle
Hydraulic Flow Rate 18 gal/min (68 L/min)
Hydraulic Pressure 2,900 psi (200 bar)
Operating Weight 9,260 lbs (4,200 kg)
Loader Bucket Capacity 1.25 – 1.5 cu yd (0.96 – 1.15 m³)
Breakout Force (Loader) 7,350 lbs (3,333 kg)
Travel Speed (Max) 20.5 mph (33 km/h)
Dimensions (L×W×H) 14.8' × 6.6' × 8.3' (4.5 × 2.01 × 2.53 m)

Performance & Design Highlights

Turbocharged Tier 3 Diesel Power

The FPT turbo diesel engine delivers reliable performance, improved torque, and good fuel economy, ideal for construction, agriculture, and utility work.

High-Capacity Loader Performance

The heavy-duty loader arms and reinforced frame provide strong lifting capability, improved stability, and extended durability in harsh job site environments.

Efficient Hydraulic System

The 570ST offers a high-flow hydraulic system for responsive loader operation, smooth lifting, and efficient material handling.

Operator Comfort & Control

A spacious open station or optional enclosed cab with ergonomic controls and excellent visibility enhances operator comfort and productivity.

Low Maintenance Emissions System

The 570ST's Tier 3 engine meets emissions requirements with simplified technology, reducing the need for complicated after-treatment systems.

Maintenance & Common Issues

Routine Maintenance

Component Service Interval
Engine Oil & Filter Replace every 500 hours
Hydraulic Fluid & Filter Service every 1,000 hours
Air Filter Inspect every 250 hours; replace as needed
Fuel Filter Replace every 500 hours
Transmission Fluid Replace every 1,000 hours
Cooling System Clean and inspect every 1,000 hours

Common Issues & Fixes

Issue Quick Fix
Hydraulic Leaks Inspect hoses, seals, and fittings regularly; replace worn components
Loader Arm Wear Replace worn pins and bushings to maintain proper loader alignment
Transmission Hesitation Inspect fluid levels; check for worn clutch or linkage components
Steering Slack Inspect and adjust steering linkage; replace worn parts
Engine Overheating Clean radiator and coolers; inspect thermostat and coolant flow

Information Guide Only
