Serial Number Location:

For Case 480F Construction King models (manufactured from 1990 to 1997), the serial number plate is typically located on the left side of the tractor frame, behind the loader arm pivot area or near the clutch housing. Always verify your serial number when ordering model-specific parts to account for production year updates.



Case 480F Serial Numbers by Year

  • 1990: #JJG0003574 – JJG0006687

  • 1991: #JJG0006688 – JJG0005346

  • 1992: #JJG0005347 – JJG0005826

  • 1993: #JJG0005827 – JJG0006646

  • 1994: #JJG0006647 –

Key Specifications

Feature Specification
Years Manufactured 1990 – 1997
Engine Model Case 4-390 (4-cylinder diesel)
Gross Horsepower 60 HP (45 kW) @ 2,100 rpm
Max Torque 165 lb-ft (224 Nm) @ 1,200 rpm
Displacement 239 cu in (3.9 L)
Transmission Type 4-speed or 8-speed mechanical shuttle
Hydraulic Flow Rate 17.5 gal/min (66.2 L/min)
Hydraulic Pressure 2,300 psi (158 bar)
Operating Weight Approximately 10,800 lbs (4,899 kg)
Loader Bucket Capacity 1.0 cu yd (0.76 m³)
Backhoe Digging Depth Up to 14' 6" (4.42 m)
Breakout Force (Loader) Approximately 5,500 lbs (2,495 kg)
Travel Speed (Max) 18 mph (28.9 km/h)
Dimensions (L×W×H) 22.0' × 6.3' × 10.5' (6.71 × 1.92 × 3.2 m)

Performance & Design Highlights

Upgraded Diesel Power

The Case 4-390 naturally aspirated diesel engine delivers reliable power, improved torque, and excellent fuel economy for digging, loading, and trenching tasks.

Mechanical Shuttle Transmission

Smooth direction changes and improved speed control with the reliable 4-speed or 8-speed mechanical shuttle transmission.

Enhanced Hydraulic System

Increased hydraulic flow and pressure over earlier models provide quicker cycle times, better lift capacity, and improved backhoe performance.

Durable Loader and Backhoe Assembly

Heavy-duty loader arms, reinforced pivot points, and improved backhoe geometry ensure stability, strength, and digging efficiency.

Operator-Friendly Controls

Improved control layout, visibility, and optional enclosed cab with heat and air conditioning enhance operator comfort and productivity.

Maintenance & Common Issues

Routine Maintenance

Component Service Interval
Engine Oil & Filter Replace every 250 hours
Hydraulic Fluid & Filter Service every 1,000 hours
Air Filter Inspect every 100 hours; replace as needed
Fuel Filter Replace every 500 hours
Transmission Fluid Replace every 1,000 hours
Cooling System Clean and inspect every 1,000 hours

Common Issues & Fixes

Issue Quick Fix
Hydraulic Hose Leaks Inspect hoses and fittings; replace worn components
Transmission Shifting Problems Check clutch adjustment; inspect linkage for wear
Loader Arm Play Inspect and replace worn pins and bushings
Backhoe Swing Wear Replace swing pivot bushings and inspect linkage regularly
Engine Overheating Clean radiator and oil coolers; check coolant system components
