Cat D4H & D5M Dozer Hydraulic Cylinders

Cat D4H/D5M Dozer Hydraulic Cylinders

Cat D4H/D5M Dozer Hydraulic Cylinders parts list
Fits Model	Description	Details	Part #	Price	Product Details
See Details	D5M, D5N	Blade Lift Cylinder	167-7551	$1,385.00	View Info
See Details	D4H XL, D4H LGP	Angle Cylinder Kit	152-6482-CT-ACBK	$1,621.00	View Info
See Details	D5M, D5M XL, D5M LGP, D4H	Blade Angle Cylinder (Less Bushings)	0	152-6482	$1,487.00	View Info
See Details	D4H XL, D4H LGP	Angle Cylinder Bushing Kit	CT-ACBK	$85.00	View Info
See Details	D4H-XL, D4H-LGP, D5M, D5M-XL, D5M-LGP	Angle Cylinder Seal Kit	185-7020	$95.00	View Info

Blade angle and lift hydraulic cylinders, seal kits, bushing kits, and complete cylinder assemblies for Caterpillar D4H and D5M series crawler dozers. Coverage spans angle cylinder components and blade lift cylinders across XL, LGP, and standard configurations.

Fits Models At A Glance

D4H Series: D4H XL, D4H LGP
D5M Series: D5M, D5M XL, D5M LGP
D5N Series: D5N

Key Notes

Cylinder Types: Blade angle cylinders and blade lift cylinders available as full assemblies or rebuild components
Rebuild Options: Seal kits and bushing kits available for cost-effective cylinder restoration
Assembly Notes: Blade angle cylinder assembly (152-6482) supplied less bushings; order bushing kit separately for complete rebuild
Cross-Series Fitment: Lift cylinder 167-7551 fits both D5M and D5N; confirm blade configuration before ordering angle components
