The serial number plate is located on the right-hand side of the lower track frame near the rear, adjacent to the final drive housing. Always verify before ordering parts to ensure correct fit.
Key Specifications
Model Years: 2025 – Present
Engine: 7.0 L, 6‑cylinder diesel, Tier 4 Final
Net Power: 310 hp @ 2,400 rpm
Operating Weight: 46,000 lb (with full fuel and standard bucket)
Rated Operating Capacity: 16,500 lb
Tipping Load: 33,000 lb
Bucket Breakout Force: 55,000 lb
Lift Height (to bucket hinge pin): 13 ft 0 in
Ground Speed: Up to 12 mph (two‑speed travel)
Ground Pressure: 8.7 psi
Track Width: 17 in
Track Length on Ground: 11 ft 0 in
Overall Width (with bucket): 9 ft 0 in
Cab Height: 9 ft 8 in
Fuel Tank Capacity: 70 gallons
Hydraulic System Capacity: 75 gallons
Auxiliary Hydraulic Flow: 65 gpm
Hydraulic Operating Pressure: 4,800 psi
Performance & Design Highlights
Heavy-Class Load Capacity: 16,500 lb rated capacity with 55,000 lb breakout force for demanding jobs
High-Flow Hydraulics: Flow-sharing pump ensures smooth and powerful attachment control
Operator Comfort: ROPS/FOPS-certified cab with air-ride suspension seat, full HVAC, and rearview camera option
Two-Speed Travel: Up to 12 mph travel; low-speed mode for precision and control under load
Durable Undercarriage: Heavy-duty rollers, reinforced frame, and robust track components
Routine Maintenance
Engine Oil & Filter: Replace every 500 hours
Hydraulic Fluid & Filters: Change hydraulic oil every 1,000 hours; filters every 500 hours
Fuel Filter: Replace every 500 hours
Air Filter: Inspect every 250 hours; replace when needed
Track Tension & Grease Points: Inspect and lubricate daily
Cooling System: Clean radiator and coolers weekly; check coolant level
Common Issues & Fixes
Track Wear or Misalignment: Daily inspection of tension, rollers, and sprockets; replace worn parts promptly
Hydraulic Hose Wear: Inspect hoses and fittings daily; replace any showing abrasion or leaks
Overheating: Keep coolers and radiator free of debris; maintain coolant within specification
Electrical Faults: Use onboard diagnostics to detect wiring, fuse, or sensor issues
Loss of Breakout Force: Inspect bucket teeth; replace and maintain clean hydraulic fluid and filters
