Part Numbers: AHC14489, AH158633, AHC20658, AH210979
Weight: 57 lbs (25.85 kg)
Bore: 100mm (3-15/16")
Rod Diameter: 50mm (1-31/32")
Stroke: 94mm (3-11/16")
Closed Length: 450.5mm (17-3/4")
Includes: Swivel bushings preinstalled on both ends — ready for direct installation
Design: Built with a serviceable piston design — unlike OEM's unitized style, this cylinder can be rebuilt in the field using John Deere bore seal kit AH212101
Application: Hydraulic blade tilt cylinder — controls side-to-side tilt of the dozer blade for grading, sloping, and finish work
Origin: Made in USA
Condition: Aftermarket replacement part
Common Use Case or Symptoms: Use when the dozer blade drifts to one side, loses tilt force, or the tilt cylinder is leaking externally — common signs of a worn or failed blade tilt cylinder on John Deere K-Series, J-Series, H-Series, and P-Tier dozers.
Why Choose Broken Tractor:
✅ Serviceable Piston Design: Built for in-field repairability — compatible with JD bore seal kit AH212101, saving you the cost of full cylinder replacement down the road
✅ Preinstalled Swivel Bushings: Bushings installed on both ends at the factory for a true drop-in installation — no press required
✅ Made in the USA: Precision-built domestic cylinder engineered to match OEM dimensions and performance across John Deere H, J, K, and P-Tier dozer and CTL applications
$1,208.00
Shipping charges are calculated at checkout.
Items are NOT guaranteed to be in stock at the time of order.
Refunds are offered if the item is on back-order.
