The serial number plate is typically located on the right-hand side of the cab, below the front windshield or inside the cab near the operator's seat. Always verify the serial number before ordering parts.
Key Specifications
Model Years: 2022 – Present
Engine: Cummins B4.5, 4-cylinder turbo diesel
Net Power: 170 hp @ 2,200 rpm (ISO 9249)
Operating Weight: 36,938 lb
Fuel Tank Capacity: 42.8 gallons
Hydraulic Fluid Capacity: 29.1 gallons
Hydraulic Pump Flow: 61.3 gpm
Hydraulic Pressure: 4,975–5,410 psi
Transmission: 2-speed hydrostatic
Travel Speed: Up to 20.6 mph
Swing Speed: 9.5 rpm
Swing Torque: 23,307 lb-ft
Tire Size: 600/40-22.5
Dimensions
Overall Length: 25.4 ft
Transport Width: 8.14 ft
Shipping Height: 10.13 ft
Tail Swing Radius: 5.48 ft
Wheelbase: 7.88 ft
Ground Clearance: 1.19 ft
Working Range
Max Digging Depth: 14.74 ft
Max Reach at Ground: 27.81 ft
Max Loading Height: 20.35 ft
Performance & Design Highlights
High-efficiency Tier 4 Final engine with no EGR
Four selectable power modes: Power, Standard, Eco, and Custom
Flow-sharing hydraulics provide responsive attachment control
Hydrostatic travel system with cruise control
Cab equipped with touchscreen display, suspension seat, and 360° visibility with radar assist
Gullwing doors for easy access to engine, hydraulics, and service checkpoints
Routine Maintenance
Engine Oil & Filter: Every 800 hours
Fuel Filters: Every 1,000 hours
Hydraulic Oil: Replace every 5,000 hours; filter every 1,000 hours
