The serial number plate is located on the right-hand side of the loader frame near the rear articulation joint, just beneath the engine compartment. Always verify this before ordering parts to ensure correct compatibility.
Key Specifications
Model Years: 1968 – 1978
Engine: Case A504BDT 8.3 L 6-cylinder turbocharged diesel (~165 hp)
Operating Weight: ~33,000 lb
Bucket Capacity: ~3.0 cubic yards heaped
Rated Operating Capacity: ~9,000 lb
Bucket Breakout Force: ~30,000 lb
Fuel Tank Capacity: ~82 gallons
Dimensions & Mobility
Length with Bucket: 27 ft 0 in
Width Over Tires: 9 ft 2 in
Height to Top of Cab: 11 ft 4 in
Wheelbase: Approximately 10 ft 2 in
Travel Speed: Up to 18 mph
Steering: Articulated frame for maneuverability
Performance & Design Highlights
Articulated Frame Design: Enhances maneuverability and control
Turbocharged Diesel Engine: Provides smooth, reliable power for mid-duty tasks
Robust Load-Sensing Hydraulics: Estimated ~52 gpm flow for versatile attachments
Power-Shift Transmission & Air Brakes: Delivers smooth operation and reliable stopping
Routine Maintenance
Engine Oil & Filter: Replace every 250–500 hours
Hydraulic Fluid & Filter: Fluid change every 1,000 hours; filter every 500 hours
Fuel Filter: Replace every 250 hours
Air Filter: Inspect every 100 hours
Greasing: Daily lubrication of articulation pivot, loader arms, bucket links
