Case 750K Dozer – Parts, Specs

Description:

Serial Number Location:

For Case 750K Dozers (manufactured from approximately 2001 to 2015), the serial number plate is typically mounted on the left side of the frame, near the articulation joint or behind the left lift cylinder. Always verify the serial number before ordering parts, as early and late 750K units may vary in emissions equipment and electronic control systems.

Key Specifications

Years Manufactured: 2001 – 2015

Engine Model: Case 6-590 (early) or electronic 6.7L (later Tier 3 models)

Net Horsepower: 96 HP @ 2,000 rpm

Displacement: 409 – 414 cu in (6.7 L)

Transmission Type: Hydrostatic transmission with dual-path, electronically controlled drive pumps

Undercarriage Type: Standard or LGP (Low Ground Pressure) options

Hydraulic Flow Rate: 23.5 – 24 gal/min

Hydraulic Pressure: 2,500 – 2,700 psi

Operating Weight: Approx. 19,800 – 21,500 lbs

Blade Capacity: 2.8 – 3.3 cubic yards

Top Travel Speed: 5.9 mph

Dimensions (L×W×H): Approx. 15.8 ft × 7.8 ft × 9.1 ft

Performance & Design Highlights

Dual-Path Hydrostatic Drive: Provides smooth, infinitely variable speed and counter-rotation capability for tight working areas or finish grading.

Tier 3 Engine (Later Models): Improved fuel economy and lower emissions with electronic fuel injection and diagnostic-ready controls.

Advanced Blade Control: Available with 6-way PAT blade and adjustable sensitivity to suit varied grading needs.

Comfortable Cab Design: Pressurized cab with improved HVAC, ergonomically placed controls, and optional suspension seat for all-day operation.

Modular Component Access: Simplifies servicing of major systems like the transmission, cooling pack, and hydraulic pumps.

Routine Maintenance

• Engine Oil & Filter: Replace every 250 hours

• Hydraulic Oil & Filters: Change every 1,000 hours

• Transmission Fluid: Inspect every 250 hours; replace every 1,000 hours

• Fuel Filters: Replace every 250 hours

• Air Filters: Inspect every 100 hours; replace as needed

• Final Drive Oil: Check every 100 hours; replace every 1,000 hours

• Track Adjustment: Grease daily and check tension on both sides

Common Issues & Fixes

Hydrostatic Response Delay: Typically caused by dirty charge filters or control calibration errors—replace filters and perform ECU reset.

Blade Tilt Drifting: Often a result of internal cylinder seal wear—reseal tilt cylinders with OEM kits.

Low Hydraulic Pressure Alarm: Inspect main relief valve and verify hydraulic fluid viscosity during colder starts.

Fuel Delivery Problems: Air leaks at fuel primer bulb or clogged primary filters—replace hoses and filters regularly.

Electronic Fault Codes (Late Models): Check for corroded ECM connectors and run diagnostics through onboard display or diagnostic port.

Track Tension Loss: Usually linked to leaking grease adjusters—replace seals and inspect recoil springs.
