Case Excavator Links, Pins & Bushings
Case excavator links, pins, and bushings for bucket and linkage repairs. This category includes heavy-duty replacement components that fit Case CX130, CX135SR, CX160, CX210, CX225SR, CX240, CX290, CX330, CX350, 9030B, 9007, 9007B, 9010, 9010B, 9020, 9040, and 9050B excavators. These parts are built to restore proper bucket-to-dipper alignment, eliminate excessive play, and correct worn linkage connections at the H-link and cylinder attachment points. Whether you’re replacing a bucket to dipper arm pin or rebuilding a worn H-link assembly, these Case excavator links and pins are designed for original-spec fit and reliable field performance.
Fits:
CX130, CX135SR, CX160
CX210, CX225SR, CX240
CX290, CX330, CX350
9030B, 9007, 9007B
9010, 9010B, 9020
9040, 9050B
Common Repair Issues
• Excessive play at bucket pivot points
• Loose bucket connection to H-link
• Knocking or clunking in linkage during operation
• Egg-shaped pin bores in dipper or link arms
• Uneven bushing wear
• Reduced breakout force from worn linkage components
Parts Covered in This Category
• Bucket to dipper arm pins
• Bucket to H-link pins
• Link to dipper pins
• Link to cylinder pins
• H-link assemblies
• Dipper to cylinder links (left and right)
• H-link bucket end bushings
• H-link cylinder end bushings
• Lower H-link and dipper link seals
These Case excavator links, pins, and bushings are manufactured from hardened, heavy-duty steel for high-load applications. Components are built for precision fit to maintain proper alignment at bucket and linkage pivot points. The CX330 and CX350 H-link assembly is Made in USA, with other parts varying by application. All components provide factory-style fit for dependable excavator linkage repair.
Key Notes:
Application: Bucket, H-link, and dipper linkage pivot points on Case excavators.
Coverage: Includes pins, bushings, links, seals, and H-link assemblies for listed models.
Material/Build: Hardened steel pins and heavy-duty linkage components; USA-made H-link available for CX330/CX350.
Function: Restores tight bucket movement, proper alignment, and digging performance.
Made In / Brands: USA-made H-link for CX330/CX350; other components vary by part.
